SCRC&SCNF
CAREFUL
SCRC&SCNF Emi&Emc suppression ferrite clamp split core is a popular products that used for the harness assembly for most of electric appliance,fitted for wire diameter range is 3mm-18mm, the core with clip plastic case for insulation,shape include round and square,The ferrite material is NiZn or MnZn, NiZn working at high frequency 1mhz-1Ghz, MnZn working at low frequency 1khz-500khz, material permeability from 40-15000 with good impedance value.
SCRC&SCNF Emi&Emc suppression ferrite clamp split core is a popular products that used for the harness assembly for most of electric appliance,fitted for wire diameter range is 3mm-18mm, the core with clip plastic case for insulation,shape include round and square,The ferrite material is NiZn or MnZn, NiZn working at high frequency 1mhz-1Ghz, MnZn working at low frequency 1khz-500khz, material permeability from 40-15000 with good impedance value.
